Tuckwell Machinery supplies and supports specialist CNC drilling machines for wood and composite panel processing, helping Australian workshops improve drilling accuracy, production speed and repeatability.
The Vitap CNC drilling machine range includes Vitap Leonardo 6-SIDE, Vitap Galileo, Vitap Kairos and Vitap K3. These machines support panel drilling, routing, channelling and machining workflows for cabinet makers, joiners and panel-processing workshops.
Whether you are comparing a compact CNC drilling machine, a CNC hole drilling machine, or a more advanced panel machining centre with DDT transport, Tuckwell Machinery can help match the right Vitap model to your workflow.
CNC drilling machines are used to automate drilling, channelling, routing and hardware preparation in cabinet panels and wood-based board products. They help reduce manual layout work, improve repeat accuracy and support faster production for custom and batch cabinet manufacturing.
The Vitap range gives workshops options from compact entry-level CNC drilling and routing through to advanced multi-face machining with DDT transport and Bar Nesting technology.
Compare the Vitap Leonardo, Galileo, Kairos and K3 CNC drilling machines for different panel-processing requirements.
The Leonardo 6-SIDE is a compact CNC drilling centre for six-face machining. It uses a reinforced tubular frame, fixed working table and symmetric head to help maintain accuracy over time.
The Galileo uses two robust grippers with a linear guide, recirculating ball screw and brushless motor control. Vitap DDT Double Dynamic Transport coordinates panel movement to help protect visible faces.
The Kairos is a compact, cost-effective CNC drilling and routing centre designed for flexible, on-demand production. Its PC-based control and modern graphical interface make it practical for everyday workshop operation.
The Vitap K3 combines cutting, profiling, drilling and routing in one machine. It machines five faces of a panel using Vitap Bar Nesting System and DDT double gripper transport.
Watch the Vitap CNC drilling machine range in operation, including Leonardo, Galileo, Kairos and K3.
Vitap Leonardo 6-SIDE CNC drilling machine.
Vitap Galileo with DDT transport system.
Vitap Kairos CNC drilling and routing machine.
Vitap K3 CNC machining centre.
The following table is a practical model overview based on the information supplied for this page. It is not a full manufacturer technical specification table. Confirm current configuration, options and availability with Tuckwell Machinery before ordering.
| Known Detail | Leonardo 6-SIDE | Galileo | Kairos | K3 |
|---|---|---|---|---|
| Machine Focus | Compact six-face CNC drilling centre | CNC drilling with DDT Double Dynamic Transport | Compact CNC drilling and routing centre | CNC machining centre for cutting, profiling, drilling and routing |
| Panel Machining | All six faces | Panel drilling and machining with protected visible faces | Drilling, channelling and pantograph machining | Five-face machining |
| Transport / Handling | Redesigned DDT Dynamic Double Transport system | Patented DDT double gripper system | Single-gripper, belt-driven panel handling | DDT double gripper transport and Bar Nesting System |
| Noted Capacity / Detail | Max panel X infinite, Y 1300, Z 80 mm; min panel X 135, Y 100, Z 3 mm | Large Y-axis area of 920 mm | Approx. 5 m² footprint; approx. 16 seconds per cycle noted in supplied content | Large Y capacity of 1250 mm; DDT range 3–50 mm |
| Tooling / Units | 6-position automatic tool changer; top and bottom drilling/router units as supplied | PC control with intuitive interface | Onboard drilling and routing units | 4-position automatic tool changer |
| Workshop Fit | For workshops needing six-face panel processing | For workshops wanting DDT handling without suction cups | For smaller workshops wanting compact CNC drilling | For workshops wanting multi-function CNC panel machining |
Specifications and machine capabilities may vary by model configuration. Please confirm current details with Tuckwell Machinery before ordering.
Tuckwell Machinery supplies CNC drilling machines for Australian woodworking, cabinet making and panel-processing workshops. Our team can help compare the Vitap Leonardo, Galileo, Kairos and K3 based on your production volume, available floor space, panel sizes and machining requirements.
We support the machines we sell with technician-led advice, installation, machine set-up, operator training, servicing support and genuine parts assistance.
Speak with Tuckwell Machinery about the Vitap Leonardo, Galileo, Kairos or K3 and which CNC drilling machine best suits your workshop.
Request a Quote Call 07 3805 5444A CNC drilling machine is used to drill accurate holes, channels and hardware positions in wood, composite and cabinet panels. These machines help improve repeatability, reduce manual marking and speed up panel production.
DDT Double Dynamic Transport uses two coordinated grippers to move panels smoothly and precisely. It helps reduce vibration, protect visible faces and improve positional accuracy for drilling and routing.
Some Vitap CNC drilling machines, including Galileo and K3 based on the supplied page information, do not require suction cups. This can simplify setup, reduce wear items and lower running costs.
The Vitap Leonardo 6-SIDE is suited to six-face machining. It uses a fixed working table and symmetric head to maintain accuracy while processing all six faces of a panel.
Yes. Tuckwell Machinery supplies, services and supports the CNC drilling machines it sells, with technician-led advice, parts support, installation, machine set-up and operator training.
