A modular CNC nesting solution with automatic loading and unloading capability, designed for efficient panel processing as a stand-alone machine or as part of an automated production line.
The Masterwood Nesting KS is a modular CNC nesting range designed to combine efficient panel machining with flexible loading, unloading and production-line integration.
Available in two current configurations, the Nesting 2131 KS and Nesting 2242 KS, the range combines a high-efficiency matrix working table, 13.2 kW HSK F63 electrospindle, integrated drilling, a 12-position tool magazine and six vacuum areas.
Masterwood designed the Nesting KS for both stand-alone production and integration into more automated manufacturing lines, giving cabinetmakers and panel processors room to increase automation as production requirements grow.
Masterwood describes the Nesting KS as a new-generation nesting range combining wide modularity with competitive investment cost. Automatic loading and unloading systems, end-of-line labelling options and flexible machine configuration allow it to be used in different levels of production automation.
For cabinetmaking and furniture production, nesting can combine routing, drilling and panel cutting operations on one CNC platform while making efficient use of full sheets.
The two current Nesting KS models provide different working envelopes while sharing the same published spindle power, axis speeds, drilling arrangement, vacuum zoning and tool magazine capacity.
A compact Nesting KS configuration for efficient full-sheet panel processing with the same core machining package as the larger model.
A larger working envelope for manufacturers needing additional X and Y capacity while retaining the same Nesting KS platform.
The Nesting KS is particularly relevant to manufacturers processing sheet materials and cabinet components where panel optimisation, routing, drilling and automated material handling can improve production flow.
Both current Nesting KS models are specified with a 13.2 kW HSK F63 electrospindle, providing a robust machining package for professional panel processing.
The published axis speeds are 40 m/min in X, 40 m/min in Y and 20 m/min in Z, with a maximum tool diameter of 80 mm.
Masterwood lists a 120 mm blade for cutting in the X axis, adding another machining function within the Nesting KS platform.
The current Nesting KS specification includes 6 vertical spindles in X and 4 vertical spindles in Y, allowing drilling operations to be completed within the CNC nesting process.
Both Nesting KS models are listed with a 12-tool magazine. Automatic tool changing allows the machine to move between suitable routing and machining tools as required by the programmed job.
The combination of CNC routing, drilling and automatic tool management helps reduce manual intervention between operations.
Masterwood highlights automatic loading and unloading systems as a key part of the Nesting KS concept. The machines can be configured for stand-alone processing or integrated into a broader production line.
This gives manufacturers a practical path from a more conventional CNC nesting setup through to increased material-handling automation as production volumes and workflow requirements change.
| Specification | Nesting 2131 KS | Nesting 2242 KS |
|---|---|---|
| Working Area X-Y-Z | 3100 × 2150 × 100 mm | 4260 × 2210 × 100 mm |
| X-Y-Z Speed | 40 / 40 / 20 m/min | 40 / 40 / 20 m/min |
| Vacuum Areas | 6 | 6 |
| Blade for Cut in X | 120 mm | 120 mm |
| Vertical Drilling Spindles | X: 6 | Y: 4 | X: 6 | Y: 4 |
| Electrospindle | 13.2 kW HSK F63 | 13.2 kW HSK F63 |
| Tool Magazine | 12 tools | 12 tools |
| Maximum Tool Diameter | 80 mm | 80 mm |
Specifications above are based on Masterwood's current published technical data for the Nesting 2131 KS and Nesting 2242 KS. Available automation, labelling and line-integration options should be confirmed with Tuckwell Machinery when specifying the machine.
See the Masterwood nesting system in operation and get a closer look at the production workflow.
Automatic loading and unloading options can reduce manual sheet handling and support a more continuous nesting workflow.
Choose between the 2131 KS and larger 2242 KS according to sheet size, component requirements and available production space.
Vertical drilling capability allows more component operations to be completed within the same CNC process.
A 12-position tool magazine supports programmed tool changes throughout the machining cycle.
The Nesting KS can operate as an individual CNC or form part of a more automated manufacturing line.
The platform is designed around flexible configuration so automation can be matched to the workshop's production requirements.
Tuckwell Machinery supplies and supports Masterwood CNC machinery in Australia. Our team can assist with machine selection, production requirements and configuration, followed by installation, commissioning, operator training and ongoing service support.
To compare the Nesting KS with other Masterwood solutions, visit our main Masterwood CNC Machines page.
The Masterwood Nesting KS is a modular CNC nesting range for panel processing. Masterwood designed it for both stand-alone operation and integration into automated production lines, with automatic loading and unloading systems available.
Masterwood currently lists the Nesting 2131 KS with a 3100 × 2150 × 100 mm working area and the Nesting 2242 KS with a 4260 × 2210 × 100 mm working area.
Both current Nesting KS models are specified with a 13.2 kW HSK F63 electrospindle.
Yes. The published drilling configuration includes six vertical spindles in the X direction and four vertical spindles in the Y direction.
Masterwood lists a 12-position tool magazine for both the Nesting 2131 KS and Nesting 2242 KS.
Yes. Masterwood specifically highlights automatic loading and unloading systems and states that the Nesting KS can be used as a stand-alone machine or integrated into a production line.
Yes. Tuckwell Machinery supplies Masterwood CNC machinery in Australia and provides assistance with machine selection and configuration, installation, commissioning, operator training, servicing and ongoing support.
Talk to Tuckwell Machinery about your sheet sizes, production volume, automation requirements and current workflow. We can help determine the most suitable Nesting KS configuration and material-handling setup for your workshop.
