Max Panel Size: X: unlimited, Y: 920 mm, Z: 50mm
Min Panel Size: X: 270/400 *, Y: 185 mm, Z: 3 mm (* 270mm with limits)
Max Panel Weight: kg 50
Spindles Speed Rotation: 3,600 RPM
Saw Blade Speed Rotation: 7,000 RPM
Panel Feeding Speed X : 25m/min
Max Drilling Depth in Vertical: 43 mm
Max Vertical Diameter of the Tools: 35mm
Drilling Motor Power: 1.7 KW
Max Horizontal Diameter of the Tools: 12 mm
Electro Spindle Power: 3.3 kW -S6 (4.5Hp – S6) 12,000 – 24000 RPM – ISO30
